Customizable purchase Products Stock Brass copper mesh shielding fabric Copper wire mesh filter copper mesh
Introduction
Material:
High-quality brass alloy (copper-zinc blend) offering excellent conductivity and corrosion resistance.
Key Features:
Good corrosion resistance (suitable for moderate environments)
High electrical & thermal conductivity
Attractive golden appearance (ideal for decorative uses)
Malleable & easy to fabricate
Non-sparking properties (safe for flammable areas)
Specifications:
- Mesh Count: 2-250 mesh
- Wire Diameter: 0.005-2mm
- Roll Width: 1m/1.2m/1.5m (customizable)
- Roll Length: Standard 30m (adjustable)
| Product name | Customizable purchase Products Stock Brass copper wire mesh |
| Material | brass wire--purity--Cu: 65% , Zn:35% red copper wire--purity--Cu:99.8% phoshpor bronze wire--purity--Cu:85%-90% , Sn:5%-15% |
| Mesh Size | 2-250 mesh |
| Wire Diameter | 0.05-2.03mm |
| Weave Style | Plain woven,Twill woven |
Application
1. Industrial Uses
EMI/RFI Shielding – Protects electronic devices from interference (ideal for aerospace, telecommunications)
Filtration Systems – Used in oil, gas, and air filters due to corrosion resistance
Safety Screens – Non-sparking properties make them safe for flammable environments
2. Architectural & Decorative
Decorative Panels & Partitions – Enhances interiors with its warm golden appearance
Ventilation Grilles– Combines functionality with visual appeal
3. Specialty Applications
Insect Screens – Durable and resistant to outdoor conditions
Art & Craft Projects– Easy to shape for creative designs
Customizable
Material Excellence
• High-grade brass alloy (65% Cu, 35% Zn standard)
• Optional phosphor bronze variants for enhanced spring properties
Customization Options:
1. Weave Configurations
Plain weave (standard square pattern)
Twill weave (diagonal pattern for finer filtration)
Dutch weave (ultra-dense for micron-level filtering)
2. Mesh Specifications
Mesh count: 2-250 mesh
Wire diameter: 0.05-2.03mm
Open area: 15%-80% adjustable
3. Dimensional Flexibility
Roll width: 100mm-3000mm
Roll length: 1m-50m continuous
Custom sheet sizes available
4. Surface Treatments
Mill finish (standard)
Anti-tarnish lacquer coating
Pre-oxidized patina finishes
5. Performance Enhancements
Reinforced selvage edges
Pre-tensioned rolls for stability
Welded intersections (for structural applications)
Advantage
Excellent Conductivity – Superior electrical and thermal performance for EMI/RFI shielding and heat dissipation.
Natural Corrosion Resistance – Withstands moisture and mild chemicals, suitable for indoor/outdoor use.
Non-Sparking & Non-Magnetic – Safe for flammable environments and sensitive electronic applications.
Aesthetic Appeal – Warm golden finish enhances architectural and design projects.
Easy to Fabricate – Soft yet durable, allowing for cutting, bending, and welding without cracking.
Cost-Effective – More affordable than stainless steel while maintaining good durability.
Antimicrobial Properties – Naturally inhibits bacterial growth (ideal for hygienic applications).
Customizable – Available in various weaves, sizes, and surface treatments.
